产品说明
|
名称
|
新机型液体机(全自动液体包装机)
|
Name
|
Liquid Machine
|
|
型号
|
HYL-50Y-2
|
Model
|
HYL-50Y
|
|
下料方式
|
流体泵计量
|
Filling
|
Fluidity pump
|
|
袋子类型
|
三边封，四边封方形袋
|
Bag style
|
Three of four sides sealed sachets,or square sachets
|
|
剂量范围
|
0-50毫升
|
Volume
|
0-50ml
|
|
制袋尺寸
|
袋长40-150mm
袋宽15-100mm
|
Bag size
|
L 40-150mm;W 15-100mm
|
|
包装速度
|
40-80包/分钟
|
Speed
|
Max 75bags/min
|
|
控制方式
|
PLC控制系统+中英文显示屏
|
Control style
|
plc control system + Chinese/English interface
|
|
机箱外观
|
钢板喷漆/不锈钢板
|
Bodyshell
|
Sheet steel spray painted / stainless steel
|
|
功率
|
主电机370W，加热总功率720W/1320W
|
Power
|
Main motor 370w,heating power 720w/1320w
|
|
电源
|
交流220V单相/380V三相
|
Power supply
|
AC220V single-phase/380V 3-phases
|
|
重量
|
净重180千克，毛重220千克
|
Weight
|
N.W180kg ; G.w200kg
|
|
外型尺寸
|
长670mm，宽520mm，高170mm
|
Dimension
|
L670mm ,W520mm, H170mm
|
|
包装材料
|
纸/聚乙烯；玻璃纸/聚乙烯；铝箔/聚乙烯；BOPP/聚乙炔烯；尼龙/CPP等。
|
Film Material
|
Paper/polyethylene;cellophane/polyethylene;plated aluminum/polyethylene
|
|
包装物料
|
液体，酱膏体，如：洗发水、果汁、沙司、番茄酱等。
|
Article
|
Liquid or paste,like shampoo,honey jelly,juice,sauce,ketchup,flavor oil , etc.
|
|
功能概述
|
HYL系列包装机可自动完成计量、制袋、填充、封合、切断、打印生产日期、切易撕口等工序。
|
Main function
|
HYL series automatic filling and packing machines can automatically accomplish measuring , making bags,filling , sealing,cutting , print codes and make easy tearing notches
|
